我們除了擁有廣泛的攪拌，分散和研磨配件，還會根據不同的要求生產和設計不同的配件。而且我們經驗豐富的工程師很樂意給你相應的建議。
1、具有5 mm孔的輕質不銹鋼分散葉輪
2、具有5 mm孔的重型不銹鋼分散葉輪
3、重型不銹鋼分散葉輪輪轂和外螺紋5毫米
4、帶輪轂和母螺紋M8的重型不銹鋼分散葉輪
5、具有16 mm孔的重型不銹鋼分散葉輪
直徑 | 序號 |
Dissolver disc ? = 20 mm | D01/001020 |
Dissolver disc ? = 25 mm | D01/001025 |
Dissolver disc ? = 30 mm | D01/001030 |
Dissolver disc ? = 40 mm | D01/001040 |
Dissolver disc ? = 50 mm | D01/001050 |
Dissolver disc ? = 60 mm | D01/001060 |
直徑 | 序號 |
Dissolver disc ? = 30 mm | D01/002030 |
Dissolver disc ? = 40 mm | D01/002040 |
Dissolver disc ? = 50 mm | D01/002050 |
Dissolver disc ? = 60 mm | D01/002060 |
直徑 | 序號 |
Dissolver disc ? = 70 mm | D01/002070-CV |
Dissolver disc ? =80 mm | D01/002080-CV |
Dissolver disc ? = 90 mm | D01/002090-CV |
直徑 | 序號 |
Dissolver disc ? = 70 mm | D01/002070 |
Dissolver disc ? =80 mm | D01/002080 |
Dissolver disc ? = 90 mm | D01/002090 |
Dissolver disc ? = 100 mm | D01/002100 |
Dissolver disc ? =125 mm | D01/002125 |
Dissolver disc ? =150 mm | D01/002150 |
直徑 | 序號 |
Dissolver disc ? = 175 mm | D01/002175 |
Dissolver disc ? =200 mm | D01/002200 |
Dissolver disc ? =225 mm | D01/002225 |
Dissolver disc ? = 250 mm | D01/002250 |
Dissolver disc ? =280 mm | D01/002280 |
Dissolver disc ? =300 mm | D01/002300 |
Dissolver disc ? =325 mm | D01/002325 |
Dissolver disc ? =350 mm | D01/002350 |
直徑 | 序號 |
Propeller blades ? = 50 mm | D01/004050 |
Propeller blades ? = 70 mm | D01/004070 |
Propeller blades ? = 100 mm | D01/004100 |
直徑 | 序號 |
Propeller blades ? = 40 mm | D01/005040 |
Propeller blades ? = 55 mm | D01/005055 |
Propeller blades ? = 80 mm | D01/005080 |
Propeller blades ? = 90 mm | D01/005090 |
Propeller blades ? = 105 mm | D01/005105 |
Propeller blades ? = 125 mm | D01/005125 |
可用尺寸 | 序號 |
Butterfly stirrer for 125 ml container (inner ? = 50 mm / H= 70 mm) | D01/BF0125 |
Butterfly stirrer for 250 ml container (inner ? = 65 mm / H= 85 mm) | D01/BF0250 |
Butterfly stirrer for 500 ml container (inner ? = 80 mm / H= 110 mm) | D01/BF0500 |
Butterfly stirrer for 1000 ml container (inner ? = 100 mm / H= 130 mm) | D01/BF1000 |
Butterfly stirrer for 2000 ml container (inner ? = 120 mm / H= 180 mm) | D01/BF2000 |
Butterfly stirrer for 3000 ml container (inner ? = 140 mm / H= 200 mm) | D01/BF3000 |
Butterfly stirrer for 5000 ml container (inner ? = 180 mm / H= 200 mm) | D01/BF5000 |
Type | ? | Height | Recommended | Recommended quantity | Recommended millbase | Order number |
MICRO | 28 mm | 17 mm | 125 ml | 50 ml | 30 - 50 ml | D01/007030 |
MINI | 40 mm | 30 mm | 250 ml | 100 ml | 50 - 100 ml | D01/007040 |
MC 25 | 60 mm | 42 mm | 500 ml | 200 ml | 100 - 200 ml | D01/007060 |
